Name: ABB-SafeRing/SafePlus-F
Brand: hzkd-power
Availability: InStock
Rating: 5 (1 reviews)

Description

Common features

All modules share many common features. These are described in the chapter “SafeRing/SafePlus configurations”.

Standard features

Threeposition switch-fuse-disconnector withupstream earthing switch mechanically linked with downstream earthing switch
Switchposition indication for switch-fuse-disconnector and earthing switches
Operatingmechanism with double springfor switch-fusedisconnector function
Commonmechanism for earthingfunctions
Fusecanisters forDIN type fuse. Only accessible when earthing switches are closed
Fuse-link/transformerrating:12 kV, max 125 A CEF fuses

24 kV, max 63 A CEF fuses

Fusetrippingarrangement
Optical fuse tripindication
Signal(1NO) from internalpressure indicator wired to terminals (only one each SF6 tank)

Optional features

Interface C (400 series bolted)

Interface C (400 series bolted) combisensors with integrated screen for voltage indication and sensors for current and voltage monitoring

Technical data

Switch-fuse-disconnector
Rated voltage	kV	12	17.5		24
Power frequency withstand voltage	kV	283)	38		50
Impulse withstand voltage	kV	95	95		125
Rated normal current	A	1)	1)		1)
Breaking capacities:
• offload transformer	A 20 20 20
Making capacity	kA 2) 2)			2)
Number of mechanical operations	1000 close/open			manual
Electrical and mechanical classes	E3, M1
Earthing switch downstream
Rated voltage	kV 12 17.5 24
Power frequency withstand voltage	kV 282) 38 50
Impulse withstand voltage	kV 95 95 125
Making capacity	kA 12.5 12.5 12.5
Short time current 1 sec.	kA 5 5 5
Number of mechanical operations	1000 close/open manual
Electrical and mechanical classes	E2, M1
